Linear fully automatic self-adhesive film belt round bottle labeling machine

Model: LC-360J

Basic Information

The inline fully automatic self-adhesive flat-surface labeling machine with a sheet-feeding mechanism is designed for the automatic top-surface labeling of flat items—such as unfolded cartons and packaging boxes, plastic bags, foil pouches, instruction leaflets, and paper cards—across industries including pharmaceuticals, food, electronics, daily chemicals, and light manufacturing.

Product Application Examples:

Reliable Access to Genuine Parts for Long-Term Machine Performance

Tags: 45 abc fgjghj hjjgf sdf sdf sdfh

Description

Technical Specifications

Model	LC-360J
Number of Labeling Heads	1
Suitable Products	硬质材料的扁形、方形、圆形等产品顶部平面一张标贴标
Conveyor Width	82.6mm(适合30-100mm宽度或直径产品贴标），可根据贴标产品制作宽度。
Conveyor Height	880mm ±50mm(可根据需求制作高度)
Label Size	标签宽度 ≤190mm. 超出此范围需要定制加高标头
Label Roll Inner Diameter	76.2mm
Label Roll Outer Diameter	≤350mm
Labeling Accuracy	≤±1mm 99.7%,标签、瓶体、操作误差不包含。
Labeling Speed	1~40m/min,3000-12000B/H(不同大小产品，速度不同)
Power Supply	2.2kW 220V/380V 50Hz
Machine Dimensions	2420 × 782 × 1680(mm)
Machine Weight	约280kg

Product Features:

Humanized touch screen, simple and intuitive operation, complete functions, and rich online help functions;
Wide range of application, capable of high-speed labeling of round bottles, 2/3 weeks, 1/2 weeks, 1/3 weeks, square bottles, and polygonal bottles. The labeling switch between bottles is simple and easy to adjust;
The labels have a high degree of overlap, and the label tape uses a deviation correction mechanism to prevent the label tape from deflecting. The three directions of X/Y/Z and the inclination of the labeling part are adjustable with a total of eight degrees of freedom, and there are no dead ends in adjustment;
Simple speed adjustment, labeling speed and bottle dividing speed can be adjusted steplessly, and can be adjusted as needed;
Flexible application, labeling products can be labeled standingly, with automatic bottle separation function, and can be produced by a stand-alone machine or connected to an assembly line;
High stability, an advanced electronic control system composed of Siemens PLC + Siemens touch screen + Japanese Yaskawa servo + German Sik label electric eye, supports 24/7 operation of the equipment;
Sturdy and durable, it adopts a three-rod adjustment mechanism and makes full use of the stability of the triangle. The whole machine is solid and durable; it is made of stainless steel and high-grade aluminum alloy and complies with GMP production requirements;
Labeling has counting and parameter storage functions, and 20 sets of labeling parameters can be preset. There is no need to reset when changing labeled products;
The optional automatic rotary bottle unscrambler is installed at the bottle inlet end, and can also be directly connected to the front-end production line to automatically send bottles into the labeling machine to increase efficiency;
A printer or inkjet printer can be optionally attached to the labeling head to enable printing of production date, batch number, barcode and other information on online labels;
The installation of a rolling belt mechanism can better solve the problem of wrinkling and blistering during high-speed labeling of round bottles, square bottles, and polygonal bottles.
